 Special Features
  Digital input :  DP(1).HDMI(2),DVI(1)... Selection 1 / DVI out ( Daisy chain)
  Support cable Lengths(20-30M) without signal loss from Matrix switcher to each screen
  HDCP support
  Lower power consumption



  Specification

          AK-46SNB

     AK-55SNB

   Panel

        Samsung 46"

  LG55" IPS or Samsung 55"

   Seam size

            5.9mm

      5.3mm or 5.7mm

   Native Resolution

        1920x 1080 (FHD)

   1920x 1080(FHD)

   Brightness

        500cd/m2, 800cd/m2

   500cd/m2, 800cd/m2

   Contrast Ration(Typ)

              3,500:1

           1,400:1

  ViewingAngle(Horiz/vert)

              178/178

           178/178

  Response time

                9ms

              10ms

  Power consumption

                220w

               280w

  Input

     DP(1).HDMI(2).DVI(1)
    -------------------------
     D-Sub.s-video.AV.Audio
     RS-232

    DP(1).HDMI(2).DVI(1)
   -----------------------
    D-Sub.s-video.AV.Audio
    RS-232

  Output

 DVI out (Daisy chain)
------------------------
 RS-232  (Daisy chain)

 DVI out (Daisy chain)
------------------------
 RS-232  (Daisy chain)

  Operation Temperature

               5-30C

            5-30C

  Humidity

              35-75%

           35-75%

  Life time

           50,000hours

        50,000hours

  Power

  AC100-240V @50/60Hz

   AC100-240V @50/60Hz

  Dimension

     1026(W)x580(H)x145(D)

    1215(W)x690(H)x145(D)

  Weight                   27kgs                  34kgs

  Accessories

  Remote control. DVI.RS-232   Remote control. DVI.RS-232


 Application
