SPEC

QTY

DEscRIPTION

SIGNAL IN PUT

1

Model1: 5Key_RGB, DVI, HDMI / Model2: 5Key_RGB, DVI, CVBS(BNC)

RESOLUTION MAX

640X480~1920×1200

AUDIO

1

2W 2CH 8Ω Speaker or Headphone Out(Option)

SPECIAL FUNCTIONS

1

Remote control(Option)

GLASS

1

AR Coating + AF Coating + Box Type Printing / 2T

DC IN PUT(12V/24V)

1

10V~36V(DC 3Pin Standard Cable 3m)

AC/DC ADAPTER

1

IN AC100~230V, OUT DC12V(24V)/5A(Option)

TOUCH SCREEN

1

PCAP Multi Touch Screen/USB Type(Option)

GLASS BONDING

OCR 1T(Option)

MODEL/SPEC

QTY

MAX RESOLUTION

DMGH-100 / 10”

1

1024 x 768

DMGH-120 / 12”

1

1024 x 768

DMGH-150 / 15”

1

1024 x 768

DMGH-170 / 17”

1

1280 x 1024

DMGH-190 / 19”

1

1280 x 1024

DMGH-215 / 21.5” Wide

1

1920 x 1080

DMGH-240 / 24” Wide

1

1920 x 1200

DMGH-260 / 26” Wide

1

1920 x 1200

DMGH-320 / 32” Wide

1

1920 x 1080
